Cob CAT6 8P8C Connector for Stranded Cable ( 2 Piece )
search
  • Cob CAT6 8P8C Connector for Stranded Cable ( 2 Piece )

Cob CAT6 8P8C Connector for Stranded Cable ( 2 Piece )

CB-RJ45-27

$5.90
inc GST
Cob CAT6 8P8C Connector for Stranded Cable ( 2 Piece )
Quantity
Out-of-Stock



Security policy



Delivery policy



Return policy

Introduction

Cob CAT6 8P8C Connector for Stranded Cable ( 2 Piece )

Specifications

nnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnn
n

Part No. CB-RJ45-27

n


Cat.6 8P8C UTP RJ45 Modular Plug with 2 Prong

n

Performance Category

n

Cat.6

n

Description

n

8P8C 2 Layers

n

Wire Insert Diameter

n

1.0mm

n

Maximum Cable O.D. Size

n

6.2mm

n

Maximum conductor W/insulation O.D. Size

n

1.0mm

n

Rated Current

n

125V,AC. 1.5A @25℃

n

Conductor type

n

Stranded

n

Insulation Resistance

n

500MΩ, Min. 100V DC /Min.

n

Insertion Force & Withdrawal Force

n

30N Max.

n

Durability

n

750 cycles min.

n

Packaging Features

n

100 or 1000pcs/bag

n

Plug Housing Material

n

UL 94V2 rated clear Polycarbonate (PC)

n

Contact Blades Material

n

30u" Gold Plated

n

Operation Temperature

n

 - 40℃ ~ 85℃

n

Storage temperature

n

 - 40℃ ~ 70℃

n

Compliance

n

UL 94V-2, ROHS and Reach

n
CB-RJ45-27
