PCI Express 2 Port RS232 Serial Card

Name: PCI Express 2 Port RS232 Serial Card
Brand: AusPC Market
SKU: PCIE-4437A
Price: 45.9 AUD
Availability: OutOfStock

PCIE-4437A

$45.90

inc GST

Quantity

Out-of-Stock

Security policy

Delivery policy

Return policy

Features

Expands 2 independent RS-232 serial ports with communication speeds up to 115.2Kbps.
High speed SUN1889 16C650 compatible UART controller on-board.
Designed to meet PCI Express Base Specification Revision 1.1.
Supports x1, x2, x4, x8, x16 (lane) PCI Express Bus connector keys.
On-chip hardware auto flow control to guarantee no data loss.
Built-in 32 byte hardware FIFO & 128K byte DMA software FIFO
Built-in ±2KV ESD protection for all serial signals.
Plug-n-Play, I/O address and IRQ assigned by BIOS.
Certified by CE, FCC, RoHS, and Microsoft WQHL approval.
Support Microsoft Windows, Linux, and DOS.

Product Description

2 ports RS-232 PCI Express Board

Interface	RS-232
Controller	SUN1889 (16C650 UART Compatible)
Bus Interface	PCI Express one lane (x1)
No. of Port	2-port
IRQ & IO	Assigned by System
FIFO	32 byte (Hardware)
Signal	TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
Baud rate	50 bps to 115.2 Kbps
Data bit	5,6,7,8
Stop bit	1,1.5,2
Parity	None, Even, Odd, Space, Mark
Flow Control	RTS/CTS(Hardware) , XON/XOFF(Software)
Protection	±2KV ESD protection for each signal Human Body Model (HBM)
PCB connector	DB9 Male

Microsoft	3.1/95/98/NT/ME/2000/XP/2003/Vista (32/64 bit)/ CE5.0/XP Embedded
Linux	Linux 2.4.x / 2.6.x
Unix	SCO Unixware 7.1.3, SCO OpenServer 5.0.6/5.0.7/6.0
DOS	DOS
