50M DVI Extender

FEATURES:

• Support video input : 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
• Signal transmission: use one cat6/7(recommend cat6) to connect the sender and receiver, and the Ethernet cable can be up to 50m.
• Comply to the standard of  IEEE-568B
• Support up to 1080P
• Support video output : 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
• DVI Input/Output Port: Standard DVI-I head, only supports Digital Video Signal.
• LED indication: when power is supplied or device is working, LED relative to is light.
• No loss of quality
• Installs in minutes
• Need DC5V/1A power supply

SPECIFICATIONS:

• Video Input/Output Port...................... ..... DVI
• Length of CAT-6 cable between Rx and TX.................Up to 50 meters
• DVI Input......................24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
• DVI Output...................24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
• Max bandwidth.................................225MHz
• Max baud rate...................................6.75Gbps
• Input/Output DVI cable distance................≤15m Use the standard DVI Cable
• Max working current.................................600mA
• Power adapter format......Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A(RX/TX)
• Operating Temperature range......................... -10 to +55℃
• Storage Temperature range....................... -20 to +60℃
• Operating Humidity range..................10 to 90%RH (No Condensation)
• Storage Humidity range....................5 to 95%RH (No Condensation)
• Dimension (L x W x H) ....................79X93.8X28 (mm)(RX/TX)
• Weight.......................................119g(TX)
• Weight.......................................118g(RX)
