HDMI 1080P Repeater 30M Range

FEATURES:

• It can buffer and amplifier the signal.
• 26 AWG HDMI Cable up to 30M
• Video Input Support: 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
• Video Output Support: 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
• No Loss of Signal Quality
• Easy Operation

SPECIFICATIONS:

• HDMI Connector.......................................Type A 19Pins Female
• HDMI Input..................24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
• HDMI Output..................24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
• Max Transmission Rate..........................  165MHz
• Max Transmission Bandwidth........................4.95Gbps
• Input Video Signal ............................1.2 volts p-p
• Output DDC Signal ........................ 5Volts p-p (TTL)
• Operating Temperature range...................... (-15 to +55℃)
• Operating Humidity range.................5 to 90%RH (No Condensation)
• Size(L*W*H) ...........................45X26X16.5 mm
• Weight.......................................30g
