PCI 8 Port Low Profile Serail Port Card
search
  • PCI 8 Port Low Profile Serail Port Card

PCI 8 Port Low Profile Serail Port Card

CTR5066AL

$169.00
inc GST
PCI 8 Port Low Profile Serail Port Card
Quantity
Out-of-Stock



Security policy



Delivery policy



Return policy

n
n
n
n
n
n

SUNIX SER5066A, Universal PCI serial communication board, allows users to add or expand eight RS-232 ports on PC-based system. The card is compatible with both 64 / 32-bit PCI architecture supporting 3.3 and 5V Bus, allowing it to be installed in virtually any PC-based systems. SUNIX SER5066A card has 128-bytes onboard FIFO buffer and compatible with 16C950 UART specification. It is designed with SUNIX UART controller, SUN1999 and as well built with many of SUNIX advanced features and technologies, making it the best solution for commercial and industrial automation applications.



n
n
n
n
n
nnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnn
Product Description8-port RS-232 Universal PCI Serial Board
InterfaceRS-232
ControllerSUNIX SUN1999 (16C950 UART Compatible)
BusUniversal PCI 64/32bit 3.3V/5V PCI Ver 3.0, 2.3, 2.2, 2.1
No. of Port8-port
IRQ & IOAssigned by System
FIFO128 byte (Hardware)
SignalTxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
Baud rate50 bps to 115.2 Kbps
Data bit5,6,7,8
Stop bit1,1.5,2
ParityNone, Even, Odd, Space, Mark
Flow ControlNone, Xon/Xoff, RTS/CTS
Protection±2KV ESD protection for each signal Human Body Model (HBM)
PCB connectorDB62 Female
Windows ClientXP / Vista / 7 / 8.x / 10 (X86/X64)
Windows Server2003 / 2008 / 2012 / 2016 (X64)
Windows EmbeddedWindows XP Embedded / POSReady 2009 / POSReady / Embedded System 2009
LinuxLinux 2.x / 3.x / 4.x
DOSDOS
FreeBSDFreeBSD 5.3~5.5 / 6.0~6.4
QNXQNX 6.3.2/6.4.0
* IBM OS/2WARP 3/WARP 4
* SCO UnixWareUnixWare 7.1.3/7.1.4/ Open Server 5.0.7/6.0
* Sun MicrosystemsSolaris 10
Note : “ * ” Supported by special inquiry.
HardwareEN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, FCC Part 15 Class B, BSMI: CNS13438, RoHS
SoftwareMicrosoft WHQL Windows
• Windows Client: XP / Vista / 7 / 8.x / 10 (X86/X64)
• Windows Server: 2003 / 2008 / 2012 / 2016 (X64)
Operation Temperature0 to 60°C (32 to 140°F)
Operation Humidity5 to 95% RH
Storage Temperature-20 to 85°C (-4 to 185°F)
PCB Dimension125 x 100 mm
BracketStandard 121 mm
Bracket Space1
n

n
n
n
n
n
n
n
DB62 to 8-port DB9 Male Connection Cable
n
    n
  • 40 cm
  • Part No.: 1WDB-62M04009D8000
  • 1 pcs.
n
CTR5066AL
