Ubiquiti airMAX LiteBeam AC 5 GHz Long-Range Station - 450+ Mbps Throughput - 26dBi Gain - 2x2 MIMI Antenna - airOS 8
search
  • Ubiquiti airMAX LiteBeam AC 5 GHz Long-Range Station - 450+ Mbps Throughput - 26dBi Gain - 2x2 MIMI Antenna - airOS 8

Ubiquiti airMAX LiteBeam AC 5 GHz Long-Range Station - 450+ Mbps Throughput - 26dBi Gain - 2x2 MIMI Antenna - airOS 8

LBE-5AC-LR | Ubiquiti

$209.00
inc GST
Ubiquiti airMAX LiteBeam AC 5 GHz Long-Range Station, 450+ Mbps Throughput, 26dBi Gain Antenna, 25+ Km Range,Inludes PoE Injector, 2Yr Warr
Quantity
Out-of-Stock



Security policy



Delivery policy



Return policy

The LiteBeam 5AC Long Range is an affordable airMAX AC CPE designed for long-distance links. Reach new customers and still maintain your great ROI.

Features:
Improved Radio Design
Improved Mounting
Improved Surge Protection
Management WiFi Radio/UISP mobile app
AirOS 8
UISP mobile app for Android and IOS

Now with airOS®8 and airView®
airOS®8 provides powerful features, including airMAX ac protocol support, real-time RF analytics, and an all-new design for enhanced usability.

High-Gain, Directional Antenna
The LiteBeam AC provides 23 dBi of gain for long-distance connectivity and uses a directional antenna pattern for improved noise immunity.

Breakthrough Industrial Design
Featuring the freedom of three-axis alignment, the LiteBeamM fully assembles in seconds – no tools needed. Only a single wrench is required for pole-mounting.

Compact in Size, Light in Weight
A lightweight form factor contained within ultra-compact packaging, the LiteBeam AC is ideal for shipping and logistics.

SPECIFICATION
Dimensions 512 x 385.75 x 258.3 mm (20.18 x 15.19 x 10.17")
Weight Without Mount: 1.360 kg (2.998 lb), With Mount 1.735 kg (3.825 lb)
Power Supply 24V, 0.3A Gigabit PoE Adapter (Included)
Max. Power Consumption 7W
Power Method Passive PoE (Pairs 4, 5+; 7, 8 Return)
Supported Voltage Range 24V ± 10%
Gain 26 dBi
Networking Interface (1) 10/100/1000 Ethernet Port
Processor Specs MIPS 74Kc
Memory 64 MB DDR2
LEDs Power, Ethernet
Channel Sizes PtP Mode: 10/20/30/40/50/60/80 MHz PtMP Mode: 10/20/30/40 MHz
Enclosure Characteristics Reflector (Aluminium) / Plastic: PC
Mounting Pole-Mounting Kit (Included)
Wind Loading 550 N @ 200 km/h (123.6 lbf @ 125 mph)
Wind Survivability 200 km/h (125 mph)
ESD/EMP Protection ± 24 kV Contact / Air
Operating Temperature -40 to 70° C (-40 to 158° F)
Operating Humidity 5 to 95% Noncondensing
Certifications CE, FCC, IC
LBE-5AC-LR

Specific References

EAN13
817882026345
