10/100/1000M Multimode Media Converter With SFP Port

Description

The media converter complies with IEEE 802.3/ab Gigabit Ethernet standard. It supports two types of media for network connection such as 10/100/1000 Base-T to 1000 Base SX/LX and connects these two types of segments. To operate smoothly this series can be used in 14 slot chassis as plug in module. This series Fiber Media Converter transforms 1000Base-T (Copper Gigabit) media to 1000Base-SX/LX (Fiber Gigabit) media and vice versa. The 1000Base-T port supports full-duplex Gigabit connection at wire speed with RJ45 connector. The fiber Gigabit connection supports shortwave (SX) or long wave (LX) laser optic with multi-mode or single-mode SFP type connector. This converter will give your Copper Gigabit connection the ability to interface with fiber connection over a distance up to 80 km! 10/100/1000 means, that media converter that converts the electrical signal of a 10/100/1000 Ethernet signal from copper to fiber. This solution will offer a low-cost integration option for network managers who want to migrate from 10/100 networks to Gigabit Ethernet. Gigabit only switches can now be connected to 10/100 networks without the need to upgrade the 10/100 side, allowing network managers to add new equipment gradually.

Main Features

• Complies with IEEE 802.3, IEEE 802.3u, IEEE802.3z, IEEE802.3ab, IEEE 802.3x auto negotiation
• Works at 10Mbps or 100Mbps, full or half duplex mode, or 1000Mbps full-duplex mode
• One SFP slot for Gigabit links
• Extends distances ranging from 550m(multi-mode fiber) to 120km(single-mode fiber)
• Supports auto MDI/MDIX function
• Status LED for easy monitoring of device status
• Supports jumbo frame size 9K bytes
• Supports independent LFP function
• External power supply
• FCC Class A & CE approved

Specifications

Interface

1 x Ethernet port (RJ45) 10/100/1000Base-Tx

1 x Optical port (SFP) 1000Base-Fx

Optical Port

• Available for 1310nm and 1550nm Single mode, and 850nm Multi mode;
• Transfer Distance: up to 120km;
• Connectors: SFP
• Fiber core: 9/125μm on single mode fiber, 50/125μm and 62.5/125μm on multi-mode fiber

Ethernet Port

• Standard: IEEE802.3, IEEE802.3u, IEEE 802.3ab, IEEE802.3x
• Available speed: force 10Mbps, force 100Mbps, force 1000Mbps and auto-detective 10/100/1000Mbps Full-Duplex and Half-Duplex auto-negotiation
• Connectors: RJ-45 Connector; MDI/MDI-X connection autosensing DIP Switch Function TP port mode Normal or Cut-Through LFP enabled (default) or disabled

LED Indicators

• Power Status, FDX, Speed, FX Link/Act, TX Link/Act

Power Requirement

• Input: 5V DC

Physical Characteristics

• Housing: Metal enclosure
• Dimensions: 94 x 70 x 26mm (Excluding the connector)
• Weight: 0.28kg

Environmental Limits

• Operating Temperature: 0°C to 50°C
• Storage Temperature: -20°C to 70°C
• Operating Humidity: 10% to 90% RH
• Storage Humidity: 5% to 90% RH
